Multifunzioni e stampanti UTAX

UTAX 301ci

multifunzione colore


Specifiche Tecniche

General
TypeDesktop
FunctionsCopy, Print, Scan, Fax
Print technologyLaser colour & mono
Original formatmax A4 from platen glass
Original feeder75 sheet A4 (standard), A6R-A4, 50-120 g/m² (simplex/duplex)
Copy/print speedmax 30 A4 pages/min in colour and b/w, duplex: max 30 A4 pages in colour and b/w
First page CopyColour: 7.8 seconds*, mono: 6.4 Seconds*
First page PrintColour: 8 seconds*, mono: 7 seconds*
Warm-up time20 seconds*
Copy resolutionmax 600 x 600 dpi
Greyscales256
Paper feed1 x 500 sheet universal cassette (A6R-A4), 100 sheet multi-bypass (A6R-A4, min 70 x 148 mm, max 216 x 356 mm)
paper weightUniversal cassette 60-220 g/m², multi bypass 60-220 g/m², duplex 60-220 g/m²
Paper output500 sheet A4
System memory1 GB RAM, (max 2 GB RAM), 32/128 GB SSD**
Continuous copying1-999
Zoom25%-400% in 1% steps
FunctionsAdjustable colour touch screen (7 inch), duplex, job reservation, job programs, continuous scan, skip blank pages, N-up, quiet mode (half speed mode), login by function, 100 management codes, skip blank pages in copy/scan mode, HyPAS capable, etc.
Dimensions/Weight
Dimensions736.6 x 550 x 507.5 mm (H x W x D; with original feeder)
Weightapprox. 49.6 kg (with original feeder)
Environment
Mains voltage220/240 V, 50 Hz
Power consumptionapprox. 1,100 W max, approx. 533 W in operation, approx. 77 W in stand-by mode, approx. 2.5 W in sleep-mode, TEC value: 1.7 KWh/week
Noise levelapprox. 45 dB(A) in operation (colour), stand-by mode: 30 dB(A) (ISO 7779/9296)
SafetyGS/TÜV, CE
Print System
TypeIntegrated within the system
Print formatsA6R-A4
Print resolutionmax 600 x 600 dpi, 9,600 x 600 dpi level
ProcessorPowerPC 465S / 1 GHz
Interfaces10/100/1000BaseTX, USB host (2), USB 2.0**, Wi-FI**
Network protocollsTCP/IP, NetBEUI
Operating systemsWindows 7/8/8.1/10, Server 2008 R2/2012 R2/2016, Mac OS ex 10.5, Novell NetWare**, Linux
EmulationsPCL6 (5c, XL), KPDL 3 (PostScript 3 compatible), XPS, Open XPS, PDF 1.7, PRESCRIBE IIc
FunctionsColor Optimizer, USB direct printing, PDF/XPS direct printing, printing of e-mails, private printing, barcode printing, quiet mode (half speed mode), Mobile Print (Android/iOS)/Apple AirPrint, Google Cloud Print
Scan System
Scan typeCCD colour & mono
Scanformatmax A4
Scan speedmono: max 40/17 A4 originals/min (simplex/duplex) with 300 dpi, Colour: max 30/13 A4 originals/min (simplex/duplex) with 300 dpi
Scan resolution200, 300, 400, 600 dpi
Scan modePhoto, text, photo/text, optimised for OCR
File formatTIFF, PDF, PDF/A, high compression PDF, encrypted PDF, JPEG, XPS, Open XPS
Interfaces10/100/1000BaseTX, USB host
Network protocollsTCP/IP
Operating systemsWindows 7/8/8.1/10, Server 2008 R2/2012 R2/2016
FunctionsScan to SMB, Scan to e-mail, Scan to FTP, Scan to USB, TWAIN scan, WIA scan, SMTP authentication, LDAP
Fax System
Optional fax system (11)
CompatibilitySuper G3
Original formatmax A4
Modem speed33.6 kbps
Transmission speed< 3 Seconds with JBIG
Compression modeJBIG, MMR, MR, MH
Fax resolutionmax 600 x 600 dpi
Fax memory8 MB (3.5 MB image memory)
Abbreviation dial200 numbers
One touch dial100 numbers
Group dial50 numbers
Operating systemsWindows 7/8/8.1/10, Server 2008 R2/2012 R2/2016
FunctionsNetwork fax driver, automatic redialling, delayed transmission
*Depending on operating status.
**optional
To enable HyPAS functionality additional memory is required.
