352ci

UTAX 352ci

[352ci]

Copia,stampa,scannerizza, fax- Multifunzione A4, 75 ppm:un vero tuttofare!

Specifiche Tecniche Brochures Manuali Immagini Driver Certificati Tutti i files

Specifiche Tecniche

Type	Desktop
Function	Copy print scan optional: fax
Print technology	Laser colour and b/w
Original format	max A4 from platen glass
Print speed (A4, Simplex) B/W	35
Copy speed (A4, Simplex) B/W	35
Print speed (A4, Duplex) B/W	35
Copy speed (A4, Duplex) B/W	35
Print speed (A4, Simplex) Colour	35
Copy speed (A4, Simplex) Colour	35
Print speed (A4, Duplex) Colour	35
Copy speed (A4, Duplex) Colour	35
1st page (printing, colour)	6.5
1st page (printing, b/w)	5.5
1st page (copying, colour)	7.3
1st page (copying, b/w)	5.9
Warm-up time	24
Copy resolution	600 x 600 dpi
Greyscales	256
Paper feed (Universal cassettes amount)	1 x 500 sheet
Paper feed (1st cassette types)	A6R-A4
Paper feed (Multi-Bypass amount)	100 sheet multi-bypass (A6R-A3)
Paper feed (Multi-Bypass types)	A6R-A4 [min 70 x 148 mm, max 216 x 356 mm] Banner: max 216 mm (width) x 1,220 mm (length)
Paper weights (Universal cassette min)	60
Paper weights (Universal cassette max)	220
Paper weights (Multi-Bypass min)	60
Paper weights (Multi-Bypass max)	220
Paper weights (Duplex min)	60
Paper weights (Duplex max)	220
Paper weights (Banner min)	129
Paper weights (Banner max)	163
Paper output	500 sheet A4
System memory (RAM)	4
System memory (SSD)	16
System memory (Optional)	320 GB HDD
Continuous copying (min)	1
Continuous copying (max)	9999
Zoom (min)	25
Zoom (max)	400
Zoom (step)	1
Functions	Adjustable colour touch screen (10.1 inch) duplex job reservation job programs continuous scan skip blank pages N-up quiet mode (half speed mode) login by function 1000 management codes encryption/overwriting of hard disk data (Data Security Kit and Trusted Platform Module)
Dimensions (height)	612.2
Dimensions (width)	550
Dimensions (depth)	508
Weight	47.4
Mains voltage	220/240 V
Utility frequency	50/60 Hz
Power consumption (max)	1338
Power consumption (busy)	563
Power consumption (standby)	81
Power consumption (sleep)	0.7
Power consumption (TEC)	0.5
Noise level (busy, b/w)	50.7
Noise level (busy, colour)	51.2
Noise level (standby)
Safety	GS/TÜV CE
Type	Integrated within the system
Print format	A6R-A4
Print resolution (min)	600 x 600 dpi
Print resolution (max)	1,200 x 1,200 dpi
Processor	Freescale QorIQ T1024 (Dual Core) 1.0 GHz
Interfaces	USB 2.0 10/100/1000BaseTX USB host (3) NFC
Network protocols	TCP/IP Net BEUI
Operating systems	Windows 7 Windows 8 Windows 8.1 Windows 10 Server 2008 R2 Server 2012 R2 Server 2016 Server 2019 Novell NetWare Linux Mac ex OS 10.9
Emulations	PCL6 (PCL 5c, XL) KPDL 3 (PostScript 3 compatible) PRESCRIBE Ilc PDF 1.7 XPS Open XPS
Functions	200 dpi USB direct printing PDF/XPS direct printing printing of e-mails private printing barcode printing quiet mode (half speed mode) Mobile Print (Android, iOS)/Apple AirPrint Google Cloud Print NFC Wi-Fi
Scan type	CCD colour and b/w
Scan format	max A4
Scan speed (Feeder 1, simplex, colour)	65
Scan speed (Feeder 1, simplex, b/w)	85
Scan speed (Feeder 1, duplex, colour)	130
Scan speed (Feeder 1, duplex, b/w)	170
Optional feeder 1	DP-5130
Scan speed (Feeder 2, simplex, colour)	60
Scan speed (Feeder 2, simplex, b/w)	60
Scan speed (Feeder 2, duplex, colour)	120
Scan speed (Feeder 2, duplex, b/w)	120
Optional feeder	DP-5120
Scan resolution	200 dpi 300 dpi 400 dpi 600 dpi
Scan mode	Photo text photo/text optimised for OCR
File types	TIFF JPEG PDF high compression PDF encrypted PDF XPS OpenXPS text-searchable PDF
Interfaces	10/100/1000BaseTX USB 2.0
Network protocol	TCP/IP
Operating systems	Windows 7 Windows 8 Windows 8.1 Windows 10 Server 2008 R2 Server 2012 R2 Server 2016 Server 2019
Functions	Scan to SMB scan to e-mail scan to FTP scan to USB TWAIN scan WSD scan SMTP authentication LDAP
Type	optional Fax System (10X)
Compatibility	Super G3
Original format	max A4
Modem speed	33.6
Transmission speed	3 seconds or less using JBIG
Compression method	JBIG MMR MR MH
Fax resolution	max 600 x 600 dpi
Fax memory	170
Abbreviated dial	2000
One touch dial	1000
Group dial	500
Operating systems	Windows 7 Windows 8 Windows 8.1 Windows 10 Server 2008 R2 Server 2012 R2 Server 2016 Server 2019
Functions	Network fax driver automatic redialling delayed transmission max 2 fax kits for parallel transmission and reception
Original feeder	DP-5100 document processor with automatic reverse function (A6R-A4, banner paper up to 1,900 mm [length], capacity: 75 sheet A4, paper weight 50-120 g/m²) DP-5120 document processor with simultaneous duplex scanning (A6R-A4, banner paper up to 1,900 mm [length], capacity: 100 sheet A4, paper weight 50-120 g/m²) DP-5130 document processor with simultaneous duplex scanning, double feed and staple detection sensors (A6R-A4, banner paper up to 1,900 mm [length], capacity: 270 sheet A4, paper weight 50-120 g/m²)
Finisher	DF-5100 internal finisher (capacity: 300 sheet A4, stapling max 50 sheet A4) DF-5110 (capacity: 1,000 sheet A4, stapling max 50 sheet A4) DF-5120 (capacity: 3,200 sheet A4, stapling max 50 sheet A4, manual stapling also available, 2-/4-hole punching) PH-5110 hole punch unit for DF-5110 (2-/4-hole punching) MT-5100 multi tray (500 sheet + 5 x 100 sheet A4; cannot be combined with DF-5100/DF-5110/DF-5210/JS-5100)
Job Separator	JS-5100 (capacity: 100 sheet A4)
Paper feed	PF-5120 (1 x 500 sheet universal cassettes [A6R-A4]) PF-5130 (2 x 500 sheet universal cassettes [A6R-A4]) PF-5140 (2,000 sheet large capacity tray [A4]) 1 x PF-5120 is required for installation of PF-5130 or PF-5140!
Other options	Card authentication kit (B) Card reader holder (11) Scan extension kit (A) UG-33 ThinPrint® kit UG-34 Emulation option kit IB-50 Gigabit Ethernet card IB-35/IB-51 WLAN card HD-11(B) (320 GB HDD) Internet fax kit (A) NK-7100(B) Numeric Keyboard (10 keys) DT-5100 document tray cabinet no. 74 (high) cabinet no. 75 (low)

neral
Type	Desktop
Functions	Copy, Print, Scan, Fax
Print technology	Laser colour & mono
Original format	max A4 from platen glass
Copy/print speed	max 35 A4 pages/min in colour and b/w, duplex: max 35 A4 pages in colour and b/w
First page (print/copy)	Colour: 6.5 seconds, mono: 5.5 seconds (print), colour: 7.3 seconds, mono: 5.9 seconds (copy)
Warm-up time	24 seconds*
Copy resolution	max 600 x 600 dpi
Greyscales	256
Paper feed	1 x 500 sheet universal cassette (A6R-A4), 100 sheet multi-bypass (A6R-A4, min 70 x 148 mm, max 216 x 356 mm), banner paper 1,220 mm [length] x 216 mm [width])
Paper weight	Universal cassette 60-220 g/m², multi bypass 60-220 g/m², duplex 60-220 g/m²
Paper output	500 sheet A4
System memory	4 GB RAM, 16 GB SSD, 320 GB hard disk**
Continuous copying	1-9,999
Zoom	25%-400% in 1% steps
Functions	Adjustable colour touch screen (7 inch), duplex, job reservation, job programs, continuous scan, skip blank pages, N-up, quiet mode (half speed mode), login by function, 1,000 management codes, skip blank pages in copy/scan mode, HyPAS capable, etc.
Dimensions/Weight
Dimensions	612.8 x 550 x 508 mm (H x W x D w/o DP)
Weight	approx. 47.4 kg (without original feeder)
Environment
Mains voltage	220/240 V, 50/60 Hz
Power consumption	approx. 1,338 W max, approx. 563 W in operation, approx. 81 W in stand-by mode, approx. 0.7 W in sleep-mode, TEC value: 0.50 KWh/week
Noise level	approx. 51.2 dB(A)/50.7 dB(A) in operation (colour & b/w), stand-by mode: immeasurable (ISO 7779/9296)
Safety	GS/TÜV, CE
Print System
Type	Integrated within the system
Print formats	A6R-A4
Print resolution	max 600 x 600 dpi, 1,200 x 1,200 dpi (reduced speed)
Processor	Freescale QorlQ T1024 / 1.0 GHz
Interfaces	10/100/1000BaseTX, USB host (3), USB 2.0
Network protocolls	TCP/IP, NetBEUI
Operating systems	Windows 7/8/8.1/10, Server 2008 R2/2012 R2/2016/2019, Mac OS ex 10.9, Novell NetWare**, Linux
Emulations	PCL6 (5c, XL), KPDL 3 (PostScript 3 compatible), XPS, Open XPS, PDF 1.7, PRESCRIBE IIc
Functions	Color Optimizer, USB direct printing, PDF/XPS direct printing, printing of e-mails, private printing, barcode printing, quiet mode (half speed mode), Mobile Print (Android/iOS)/Apple AirPrint, Google Cloud Print, NFC, Wi-Fi**
Scan System
Scan type	CCD colour & mono
Scanformat	max A4, banner up to 1,900 mm (b/w only)
Scan speed	b/w: max 85/170 A4 originals/min (simplex/duplex) with 300 dpi, colour: max 65/130 A4 originals/min (simplex/duplex) with 300 dpi (DP-5130), b/w: max 60/120 A4 originals/min (simplex/duplex) with 300 dpi, colour: max 60/120 A4 originals/min (simplex/duplex) with 300 dpi (DP-5120)
Scan resolution	200, 300, 400, 600 dpi
Scan mode	Photo, text, photo/text, optimised for OCR
File format	TIFF, PDF, PDF/A, high compression PDF, encrypted PDF, JPEG, XPS, Open XPS, text-searchable PDF**
Interfaces	10/100/1000BaseTX, USB host
Network protocolls	TCP/IP
Operating systems	Windows 7/8/8.1/10, Server2008 R2/2012 R2/2016/2019
Functions	Scan to SMB, Scan to e-mail, Scan to FTP, Scan to USB, TWAIN scan, WIA scan, SMTP authentication, LDAP
Fax System
Optional fax system (10X)
Compatibility	Super G3
Original format	max A4
Modem speed	33.6 kbps
Transmission speed	< 3 Seconds with JBIG
Compression mode	JBIG, MMR, MR, MH
Fax resolution	max 600 x 600 dpi
Fax memory	170 MB
Abbreviation dial	2,000 numbers
One touch dial	1,000 numbers
Group dial	500 numbers
Operating systems	Windows 7/8/8.1/10, Server 2008 R2/2012 R2/2016/2019
Functions	Network fax driver, automatic redialling, delayed transmission, max. 2 fax kits for parallel transmission and reception
*Depending on operating status.
**optional
