UTAX P-3527w MFP
[P-3527w]Multifunzione copia/stampa/scanner
Specifiche Tecniche
Type |
Desktop
|
|
Function |
scan
fax
print
Copy
|
|
Print technology |
Laser colour and b/w
|
|
Original format |
max A4 from platen glass
|
|
Original feeder |
50 sheet A4 (standard, A6R-A4), 50-160 g/m² (with simultaneous duplex scanning)
|
|
1st page (printing, b/w) |
6.8
|
|
1st page (copying, b/w) |
6.9
|
|
Warm-up time |
20
|
|
Copy resolution |
600 x 600 dpi
|
|
Greyscales |
256
|
|
Paper feed (Universal cassettes amount) |
1 x 250 sheet
|
|
Paper feed (Multi-Bypass amount) |
100 sheet multi-bypass (A6R-A3)
|
|
Paper weights (Universal cassette min) |
163
|
|
Paper weights (Universal cassette max) |
60
|
|
Paper weights (Multi-Bypass min) |
220
|
|
Paper weights (Multi-Bypass max) |
60
|
|
Paper weights (Duplex min) |
163
|
|
Paper weights (Duplex max) |
60
|
|
Paper output |
150 sheet A4
|
|
System memory (RAM) |
512
|
|
System memory (RAM max) |
1536
|
|
Continuous copying (min) |
1
|
|
Continuous copying (max) |
999
|
|
Zoom (min) |
25
|
|
Zoom (max) |
400
|
|
Zoom (step) |
1
|
|
Functions |
Touch screen
duplex
job programs
ID card copy
continuous scan
skip blank pages
job reservation
N-up
quiet mode (half speed mode)
100 management codes
|
|
Dimensions (height) |
437
|
|
Dimensions (width) |
417
|
|
Dimensions (depth) |
412
|
|
Weight |
19
|
|
Mains voltage |
220/240 V
|
|
Power consumption (max) |
982
|
|
Power consumption (busy) |
661
|
|
Power consumption (standby) |
21
|
|
Power consumption (sleep) |
1
|
|
Power consumption (TEC) |
0.43
|
|
Noise level (standby) |
47.2
|
|
Safety |
CE
GS/TÜV
|
|
Type |
Integrated within the system
|
|
Print format |
A6R-A4
|
|
Print resolution (min) |
600 x 600 dpi
|
|
Print resolution (max) |
1,200 x 1,200 dpi
|
|
Processor |
Cortex-A9, 800 MHz
|
|
Interfaces |
USB 2.0
10/100/1000BaseTX
USB host
Wi-Fi
|
|
Network protocols |
TCP/IP
Net BEUI
|
|
Operating systems |
Windows Vista
Windows 7
Windows 8.1
Windows 10
Server 2012 R2
Windows XP
Server 2008 R2
Windows 8
Linux
|
|
Emulations |
KPDL 3 (PostScript 3 compatible)
PRESCRIBE Ile
PCL6 (PCL 5c, XL)
Line Printer
IBM Proprinter
Epson LQ-850
PDF 1.7
XPS
Open XPS
|
|
Functions |
USB direct printing
printing of e-mails
PDF direct printing
private printing
barcode printing
WSD-/Internet printing
Mobile Print (Android/iOS)
Google Cloud Print
Wi-Fi Direct®
|
|
Scan type |
CIS colour and b/w
|
|
Scan format |
max A4
|
|
Scan resolution |
200 dpi
300 dpi
400 dpi
600 dpi
|
|
Scan mode |
text
photo/text
optimised for OCR
|
|
File types |
JPEG
TIFF
PDF
high compression PDF
PDF/A-1
XPS
|
|
Interfaces |
10/100/1000BaseTX
USB 2.0
|
|
Network protocol |
TCP/IP
|
|
Operating systems |
Windows XP
Windows Vista
Windows 7
Windows 8
Windows 8.1
Windows 10
Server 2003
Server 2008
Server 2012 R2
|
|
Functions |
Scan to SMB
scan to FTP
scan to USB
TWAIN scan
SMTP authentication
WIA scan
scan to e-mail
LDAP
|
|
Compatibility |
Super G3
|
|
Original format |
max A4
|
|
Modem speed |
33.6
|
|
Transmission speed |
3 seconds or less using JBIG
|
|
Compression method |
JBIG
MMR
MH
MR
|
|
Fax resolution |
Standard (200 x 100 dpi)
fine (200 x 200 dpi)
super fine (200 x 400 dpi)
ultra fine (400 x 400 dpi)
|
|
Fax memory |
3.5
|
|
Abbreviated dial |
200
|
|
One touch dial |
100
|
|
Group dial |
50
|
|
Operating systems |
Windows XP
Windows Vista
Windows 7
Windows 8
Windows 8.1
Server 2003
Server 2008
Server 2012 R2
|
|
Functions |
Network fax driver
automatic redialling
delayed transmission
|
|
Paper feed |
max 2 x PF-1100 (250 sheet universal cassettes [A6R-A4, 60-163 g/m²])
|
|
Other options |
Card authentication kit (B)
UG-33 ThinPrint® kit
cabinet no. 78
|
