UTAX P-C3566i
[P-C3566i]multifunzione colore
Specifiche Tecniche
Type |
Desktop
|
|
Function |
Copy
print
scan
fax
|
|
Print technology |
Laser colour and b/w
|
|
Original format |
max A4 from platen glass
|
|
Original feeder |
100 sheet A4 (dual-scan document processor), A6R-A4, 50-120 g/m² (simplex/duplex)
|
|
Print speed (A4, Simplex) B/W |
35
|
|
Copy speed (A4, Simplex) B/W |
17
|
|
Print speed (A4, Simplex) Colour |
35
|
|
Print speed (A4, Duplex) Colour |
17
|
|
1st page (printing, colour) |
7.5
|
|
1st page (printing, b/w) |
6
|
|
1st page (copying, colour) |
8.5
|
|
1st page (copying, b/w) |
7.5
|
|
Warm-up time |
25
|
|
Copy resolution |
600 x 600 dpi
|
|
Greyscales |
256
|
|
Paper feed (Universal cassettes amount) |
1 x 250 sheet
|
|
Paper feed (1st cassette types) |
A6R-A4
|
|
Paper feed (Multi-Bypass amount) |
100 sheet multi-bypass (A6R-A3)
|
|
Paper feed (Multi-Bypass types) |
A6R-A4 [min 70 x 148 mm, max 216 x 356 mm]
|
|
Paper weights (Universal cassette min) |
60
|
|
Paper weights (Universal cassette max) |
163
|
|
Paper weights (Multi-Bypass min) |
60
|
|
Paper weights (Multi-Bypass max) |
220
|
|
Paper weights (Duplex min) |
60
|
|
Paper weights (Duplex max) |
163
|
|
Paper output |
250 sheet A4
|
|
System memory (RAM) |
1
|
|
System memory (RAM max) |
3
|
|
System memory (Optional) |
32/128 GB SSD
|
|
Continuous copying (min) |
1
|
|
Continuous copying (max) |
999
|
|
Zoom (min) |
25
|
|
Zoom (max) |
400
|
|
Zoom (step) |
1
|
|
Functions |
Adjustable colour touch screen (7 inch)
duplex
job reservation
job programs
ID card copy
continuous scan
skip blank pages
N-up
quiet mode (half speed mode)
login by function
100 management codes
|
|
Dimensions (height) |
619.5
|
|
Dimensions (width) |
480
|
|
Dimensions (depth) |
577
|
|
Weight |
36.5
|
|
Mains voltage |
220/240 V
|
|
Utility frequency |
50 Hz
|
|
Power consumption (max) |
1346
|
|
Power consumption (busy) |
521
|
|
Power consumption (standby) |
84
|
|
Power consumption (sleep) |
0.6
|
|
Power consumption (TEC) |
0.49
|
|
Noise level (busy, b/w) |
50.4
|
|
Noise level (standby) |
29.6
|
|
Safety |
GS/TÜV
CE
|
|
Type |
Integrated within the system
|
|
Print format |
A6R-A4
|
|
Print resolution (min) |
600 x 600 dpi
|
|
Print resolution (max) |
1,200 x 1,200 dpi (reduced speed)
|
|
Processor |
ARM Cortex-A9 Dual core 1.2 GHz
|
|
Interfaces |
USB 2.0
10/100/1000BaseTX
USB host (2)
Wi-Fi
|
|
Network protocols |
TCP/IP
Net BEUI
|
|
Operating systems |
Windows 7
Windows 8
Windows 8.1
Windows 10
Server 2008 R2
Server 2012 R2
Server 2016
Server 2019
Novell NetWare
Linux
Mac ex OS 10.5
|
|
Emulations |
PCL6 (PCL 5c, XL)
KPDL 3 (PostScript 3 compatible)
PRESCRIBE Ilc
XPS
PDF 1.7
|
|
Functions |
200 dpi
USB direct printing
PDF/XPS direct printing
printing of e-mails
private printing
quiet mode (half speed mode)
barcode printing
Mobile Print (Android, iOS)/Apple AirPrint
Google Cloud Print
Wi-Fi
|
|
Scan type |
CCD colour and b/w
|
|
Scan format |
max A4
|
|
Scan speed (Feeder 1, simplex, colour) |
40
|
|
Scan speed (Feeder 1, simplex, b/w) |
60
|
|
Scan speed (Feeder 1, duplex, colour) |
46
|
|
Scan speed (Feeder 1, duplex, b/w) |
62
|
|
Scan resolution |
200 dpi
300 dpi
400 dpi
600 dpi
|
|
Scan mode |
text
photo/text
optimised for OCR
|
|
File types |
TIFF
JPEG
PDF
PDF/A-1
PDF/A-2
high compression PDF
encrypted PDF
XPS
OpenXPS
MS Office/text-searchable PDF
|
|
Interfaces |
10/100/1000BaseTX
USB 2.0
|
|
Network protocol |
TCP/IP
|
|
Operating systems |
Windows 7
Windows 8
Windows 8.1
Windows 10
Server 2008 R2
Server 2012 R2
Server 2016
Server 2019
|
|
Functions |
Scan to SMB
scan to e-mail
scan to FTP
scan to USB
TWAIN scan
WIA scan
SMTP authentication
LDAP
|
|
Type |
Integrated within the system
|
|
Compatibility |
Super G3
|
|
Original format |
max A4
|
|
Modem speed |
33.6
|
|
Transmission speed |
3 seconds or less using JBIG
|
|
Compression method |
JBIG
MMR
MR
MH
|
|
Fax resolution |
Standard (200 x 100 dpi)
fine (200 x 200 dpi)
super fine (200 x 400 dpi)
ultra fine (400 x 400 dpi)
|
|
Fax memory |
8
|
|
Fax memory (image) |
3.5
|
|
Abbreviated dial |
200
|
|
One touch dial |
100
|
|
Group dial |
50
|
|
Operating systems |
Windows 7
Windows 8
Windows 8.1
Server 2008 R2
Server 2012 R2
Server 2016
|
|
Functions |
Network fax driver
automatic redialling
delayed transmission
|
|
Finisher |
MS-5100 manual stapler for 20 sheet
|
|
Paper feed |
max 3 x PF-5100 (500 sheet universal cassettes [A5R-A4, 60-220 g/m²])
|
|
Other options |
Data security kit (E)
Scan extension kit (A)
Card authentication kit (B)
Card reader holder (10)
UG-33 ThinPrint® kit
IB-50 Gigabit Ethernet card
IB-36 or IB-51 WLAN card
HD-6 SSD (32 GB)
HD-7 SSD (128 GB)
cabinet no. 72 (high)
cabinet no. 73 (low)
|
